Operating your monitor | 29
2&3
Power on/off button (with
LED indicator)
Use the power button to turn the monitor on and
off.
Solid white light indicates the monitor is turned
on. Blinking white light indicates it is in power-
save mode.
OSD controls
Use the buttons on the front of the monitor to adjust the image settings.
1 234
Front Panel Button Description
1
Up
Use the up button to increase values or move up in a
menu.
2
Down
Use the down button to decrease values or move
down in a menu.
3
OK
Use the OK button to confirm your selection in a
menu.
4
Back
Use the back button to go back to the previous menu.
