Dell p4317q [6/53] Product features
![Dell p4317q [6/53] Product features](/views2/1218071/page6/bg6.png)
6 | About your monitor
∞
mDP to DP cable
∞
DP to DP cable
∞
USB 3.0 upstream cable
(enables the USB ports on
the monitor)
Dell
TM
UltraSharp U2715H Monitor
∞
Drivers and
Documentation Guide
∞
Quick Setup Guide
∞
Safety and Regulatory
Information
Product features
The Dell P4317Q flat panel display has an active matrix, Thin-Film Transistor (TFT),
Liquid Crystal Display (LCD), and LED backlight. The monitor features include:
∞
107.98 cm (42.51 inch) viewable area display (measured diagonally). 3840 x 2160
resolution, plus full-screen support for lower resolutions.
∞
Plug and play capability if supported by your system.
∞
VGA and HDMI (MHL) and DP and mDP connectivity makes it simple and easy to
connect with legacy and new system.
∞
Build-in Speaker (8W x 2).
∞
On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
∞
Software and documentation media includes an Information File (INF), Image
Color Matching File (ICM), and product documentation.
∞
Dell Display Manager Software included (in the CD shipped with the monitor).
∞
Support PIP and PBP Function.
