Dell p4317q [5/53] Package contents
![Dell p4317q [5/53] Package contents](/views2/1218071/page5/bg5.png)
About your monitor | 5
About your monitor
Package contents
Your monitor ships with the components shown below. Ensure that you have
received all the components and Contacting Dell if something is missing.
NOTE: Some items may be optional and may not ship with your monitor. Some
features or media may not be available in certain countries.
NOTE: To set up with any other stand, please refer to the respective stand setup
guide for setup instructions.
∞
Monitor
∞
Stand riser
∞
Stand base
3
2
∞
VESA cover
∞
Power cable (varies by
countries)
∞
HDMI cable
