About your monitor | 7
Monitor specifications
Model P4317Q
Screen type Active matrix - TFT LCD
Panel type In-plane Switching
Viewable image
Bezel width
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
566.40 mm (22.30 in)
107.98 cm (42.51 in)
941.18 mm (37.05 in)
529.42 mm (20.84 in)
1274.79 cm
2
(197.59 inch
2
)
Pixel pitch 0.2451 x 0.2451 mm
Viewing angle (vertical
/ horizontal)
178° / 178° (typical)
Brightness 350 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Aspect Ratio 16:9
Display screen coating Anti-Glare with 2H hardness
Backlight Technology white LED edgelight system
Response time 8 ms
Color depth 1.06 Billion colors
PIP / PBP Yes
Connectivity 1 x DP 1.2
1 x mDP 1.2
2 x HDMI 1.4 (MHL)
1 x VGA
1 x USB 3.0 port - Upstream
4 x USB 3.0 port
1 x Audio Input
1 x Headphone Output
1 x RS232
Audio output 8W x 2
Built in device - usb Upstream x 1
Downstream x 4 (including one Charging Port)
