44 | Operating your monitor
If VGA, HDMI, DP or mDP cable is not connected, a floating dialog box as shown
below appears. The monitor will enter Power Save Mode after 4 minutes if left at this
state.
Dell P4317Q
No VGA Cable
The display will go into Power Save Mode in 4 minutes.
www.dell.com/support/monitors
?
Dell P4317Q
The display will go into Power Save Mode in 4 minutes.
www.dell.com/support/monitors
No HDMI Cable
?
Dell P4317Q
The display will go into Power Save Mode in 4 minutes.
www.dell.com/support/monitors
No DP Cable
?
Dell P4317Q
No mDP Cable
The display will go into Power Save Mode in 4 minutes.
www.dell.com/support/monitors
?
See Troubleshooting for more information.
