Asus PRIME X370-PRO [18/99] System memory
![Asus PRIME X370-PRO [18/99] System memory](/views2/1233072/page18/bg12.png)
1-4
Chapter 1: Product Introduction
Chapter 1
1.1.3 Central Processing Unit (CPU)
ThemotherboardcomeswithaAM4socketforAMDRyzen™/7thGenerationA-series/Athlon™
Processors
.
PRIME X370-PRO
PRIME X370-PRO CPU socket AM4
TheAM4sockethasadifferentpinoutfromtheAM3+/FM2+/FM2socket.Ensurethatyou
useaCPUdesignedfortheAM4socket.TheCPUtsinonlyonecorrectorientation.DO
NOTforcetheCPUintothesockettopreventbendingthepinsanddamagingtheCPU!
1.1.4 System memory
ThemotherboardcomeswithfourDDR4(DoubleDataRate4)QuadInlineMemoryModules
(DIMM)slots.
ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.DONOT
installaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.
PRIME X370-PRO
PRIME X370-PRO 288-pin DDR4 DIMM sockets
DIMM_A1
DIMM_A2
DIMM_B1
DIMM_B2
