ASUS PRIME X370-PRO
1-7
Chapter 1
• DuetoCPUlimitation,PCIe3.0/2.0x16_1workingat@x16orx8variesbyprocessor
whenusingonegraphicscard.
• WerecommendthatyouprovidesufcientpowerwhenrunningCrossFireX™orSLI
®
mode.
• Connectchassisfanstothemotherboardchassisfanconnectorswhenusingmultiple
graphicscardsforbetterthermalenvironment.
IRQ assignments for this motherboard
A B C D E F G H
PCIex16_1 - - - shared - - - -
PCIex16_2 shared - - - - - - -
PCIex16_3 - shared - - - - - -
PCIex1_1 - - shared - - - - -
PCIex1_2 - - - shared - - - -
PCIex1_3 - - - shared - - - -
M.2 - - - shared - - - -
CPUUSB3.0XHCI
Controller
- - shared - - - - -
AMDChipsetXHCI
Controller
shared - - - - - - -
SATAController - - - shared - - - -
HDAudioController - - - - - - shared -
IntelLAN - - shared - - - - -
ASMediaConnector shared - - - - - - -
For AMD 7th Generation A-series/Athlon™ Processors
A B C D E F G H
PCIex16_1 - - - - - - shared -
PCIex16_2 shared - - - - - - -
PCIex16_3 - shared - - - - - -
PCIex1_1 - - shared - - - - -
PCIex1_2 - - - shared - - - -
PCIex1_3 - - - shared - - - -
M.2 shared - - - - - - -
CPUUSB3.0XHCI
Controller
- - - - - - - shared
AMDChipsetXHCI
Controller
shared - - - - - - -
SATAController - shared - - - - - -
HDAudioController - - - shared - - - -
IntelLAN - - shared - - - - -
ASMediaConnector shared - - - - - - -
For AMD Ryzen™ Processors
