PRIME X370-PRO specifications summary
(continued on the next page)
LAN
Intel® I211AT Gigabit LAN
Audio
Realtek® S1220A 8-channel high definition audio CODEC
- Audio Shielding: Ensures precision analog/digital separation and greatly reduces
multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard
the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive sound
with exceptional clarity and delity
- Supports jack-detection, multi-streaming, front panel jack-retasking
- High quality 120dB SNR stereo playback output (Line-out@back) & 113dB SNR
input (Line-in) support
- Optical S/PDIF out port at back I/O
USB
AMD Ryzen™/7th Generation A-series/Athlon™ Processors
- 4 x USB 3.0/2.0 ports (4 ports at back panel[blue])
AMD X370 Chipset
- 1 x USB 3.1/3.0/2.0 front panel connector
- 4 x USB 3.0/2.0 ports (2 ports at mid-board; 2 ports at back panel,Type-A[blue]
and Type-C)
- 4 x USB 2.0/1.1 ports at mid-board
ASMedia USB 3.1 controllers
- 2 x USB 3.1/3.0/2.0 ports (2 ports at back panel[teal blue])
ASUS
Exclusive
Features
<Performance Optimization>
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates TPU, EPU,
DIGI+ VRM, Fan Xpert 4, and Turbo App.
DIGI+ VRM
- 6+4 Phase digital power design
TPU
- Auto Tuning
EPU
- EPU
Fan Xpert 4 featuring system performance tuning, network priority, and audio
scene conguration for selected applications
Turbo App featuring system performance tuning, network priority, and audio
scene conguration for selected applications.
Gaming Scenario
AURA
- Bright up your Build
Audio Features
- Audio that roars on the battleeld
