ASUS PRIME X370-PRO
3-23
Chapter 3
CPU Lower Temperature [40]
Use the <+> or <-> keys to adjust the CPU fan’s lower temperature. The values range
from 0°C to 75°C.
CPU Fan Min. Duty Cycle(%) [60]
Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The values
range from 20% to 100%. When the CPU temperature is under the lower limit, the CPU
fan will operate at the minimum duty cycle.
Chassis Fan(s) Configuration
Chassis Fan1/2 Q-Fan Control [Auto]
[Disabled] Disables the chassis Q-Fan control feature.
[Auto] Enables the Chassis Q-Fan control for 4-pin Chassis fan.
[PWM mode] Enables the chassis Q-Fan control in PWM mode for 4-pin
chassis fan.
[DC mode] Enables the chassis Q-Fan control in DC mode for 3-pin
chassis fan.
The following items appear only when you set the Chassis Fan 1/2 Q-Fan Control to
[Auto], [PWM Mode] or [DC Mode].
Chassis Fan 1/2 Q-Fan Source [CPU]
This item controls the assigned fan according to the selected temperature
source. Conguration options: [CPU] [Motherboard] [VRM] [PCH] [T_
Sensor] [Multiple Sources]
Chassis Fan 1/2 Speed Low Limit [600 RPM]
This item allows you to disable or set the chassis fan warning speed.
Conguration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM]
[600 RPM]
Chassis Fan 1/2 Profile [Standard]
This item allows you to set the appropriate performance level of the chassis
fan.
[Standard] Sets to [Standard] to make the chassis fan automatically
adjust depending on the chassis temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan
operation.
[Turbo] Sets to [Turbo] to achieve maximum chassis fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control
parameters.
The following six items appear only when you set Chassis Fan 1/2 Profile to [Manual].
Chassis Fan 1/2 Upper Temperature [70]
Use the <+> or <-> keys to adjust the upper limit of the chassis
temperature. The values range from 40°C to 75°C.
Chassis Fan 1/2 Max. Duty Cycle(%) [100]
Use the <+> or <-> keys to adjust the maximum chassis fan duty cycle. The
values range from 60% to 100%. When the chassis temperature reaches
the upper limit, the chassis fan will operate at the maximum duty cycle.
