ASUS PRIME X370-PRO
1-17
Chapter 1
11. M.2socket(M.2(Socket3))
ThesesocketsallowyoutoinstallaM.2SSDmodule.
• M.2socketsupportsPCIe3.0x4andSATAmodeMKeydesignandtype2242/2260
/2280/22110PCIeandSATAstoragedevices.
• DuetoCPUlimitation,M.2workingat@PCIe3.0x4orx2variesbyprocessors.
TheM.2SSDmoduleispurchasedseparately.
PRIME X370-PRO
PRIME X370-PRO M.2(SOCKET3)
M.2(SOCKET3)
228022110 2260 2242
12. Serial port connector (10-1 pin COM)
Thisconnectorisforaserial(COM)port.Connecttheserialportmodulecabletothis
connector,theninstallthemoduletoaslotopeningatthebackofthesystemchassis.
PRIME X370-PRO
PRIME X370-PRO Serial port (COM) connector
PIN 1
COM
DCD
TXD
GND
RTS
RI
RXD
DTR
DSR
CTS
TheCOMmoduleispurchasedseparately.
