x
(continued on the next page)
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst IV
Multi-GPU support
Supports NVIDIA
®
2-Way/Quad-GPU SLI
®
Technology
Supports AMD
®
3-Way/Quad-GPU CrossFireX™ Technology
Audio
ROG SupremeFX S1220 8-Channel high-definition CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- ES9023P High Denition DAC
- SupremeFX Shielding Technology
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features:
- Sonic Studio III
- Sonic Radar III
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio
USB
Intel
®
Z270 Chipset:
- 6 x USB 3.0 ports ( 4 ports at back panel [blue], 2 ports at mid-
board [grey])
- 6 x USB 2.0 ports ( 4 ports at back panel [black], 2 ports at mid-
board [black])*
ASMedia
®
USB 3.1 controller:
- 1 x USB 3.1 front panel connector
- 2 x USB 3.1 ports ( 1 Type-A [red] and 1 Type-C [black] at back
panel)
* 2 x USB 2.0 ports at mid-board share with ROG extension (ROG_EXT)
port.
Back I/O Ports
1 x Clear CMOS Button
1 x BIOS Flashback Button
1 x M.2 Wi Slot*
1 x HDMI 1.4b
1 x DisplayPort 1.2
4 x USB 2.0 ports [black]
4 x USB 3.0 ports [blue]
1 x Anti-surge LAN (RJ45) port
2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C [black])
1 x Optical S/PDIF out
5 x Gold-plated audio jacks
* The M.2 Wifi module is purchased separately.
MAXIMUS IX HERO specifications summary
