ix
MAXIMUS IX HERO specifications summary
(continued on the next page)
CPU
Intel
®
Socket 1151 for 7th / 6th Generation Core™ i7 / Core™ i5 /
Core™ i3 / Pentium
®
/ Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* Intel
®
Turbo Boost Technology 2.0 support depends on the CPU type
Chipset
Intel
®
Z270 Chipset
Memory
4 x DIMM, max. 64GB DDR4 4133+(OC)* / 4000(OC)* / 3866(OC)*
/ 3733(OC)* / 3600(OC)* / 3466(OC)* / 3400(OC)* / 3333(OC)* /
3300(OC)* / 3200(OC)* / 3000(OC)* / 2800(OC)* / 2666(OC)* /
2400(OC)* / 2133
MHz, non-ECC, un-buffered memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs.
**
Please refer to Memory QVL (Qualified Vendors List) for details.
Expansion slots
New 7th Gen Intel
®
Core™ Processors
2 x PCIe 3.0 x16 slots (supports x16, x8/x8)
Intel
®
Z270 Chipset
1 x PCIe 3.0 x16 slot (max. at x4 mode)
3 x PCIe 3.0 x1 slots
Graphic
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support : HDMI/DisplayPort
- Supports DisplayPort 1.2 with max. resolution 4096 x 2304 @
60Hz
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24Hz
Maximum shared memory of 1024MB
Storage
Intel
®
Z270 Chipset with RAID 0, 1, 5, 10, and Intel Rapid
Storage Technology 14 support
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices
support (both SATA & PCIE mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage
devices support(PCIE mode)
- 6 x SATA 6Gb/s ports**
- Supports Intel
®
Smart Response Technology***
- Ready for Intel
®
Optane Memory****
* When the M.2_1 Socket 3 is operating in SATA mode, SATA port
SATA6G_1 will be disabled. When the M.2_2 Socket 3 is operating in
PCIEX4 mode, SATA port SATA6G_56 will be disabled.
** These SATA ports are for data hard drives only. ATAPI devices are not
supported.
*** This function will work depending on the CPU installed.
**** Intel
®
Optane Technology only supported when using 7th Generation
Intel
®
Processors. Before using Intel
®
Optane memory modules,
ensure that you have updated your motherboard drivers and BIOS to
the latest version from ASUS support website.
