xii
(continued on the next page)
Internal I/O Ports
1 x USB 3.1 front panel connector
1 x USB 3.0 header supports additional 2 USB 3.0 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports [ via
ROG_EXT header]
6x SATA 6Gb/s ports
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices
support (both SATA & PCIE mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage
devices support(PCIE mode)
1 x ROG extension (ROG_EXT) header
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU_OPT fan connector
3 x 4-Pin Chassis fan connectors
1 x EXT_Fan header
1 x 4-Pin W_PUMP+ connector
1 x W_IN header
1 x W_OUT header
1 x W_FLOW header
1 x 4-Pin AIO_PUMP connector
1 x H_AMP fan connector
1 x Thermal sensor connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x Start button
1 x Reset button
1 x Safe Boot button
1 x Retry button
1 x LN2 mode jumper
1 x Slow mode switch
1 x MemOK! Button
1 x Clear CMOS Button
1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX III series
support
1 x Front panel audio connector (AAFP)
1 x TPM connector
1 x System panel connector
2 x AURA RGB headers
BIOS
1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0,
SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash
3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control,
F3 My Favorites, Last Modied log, F12 PrintScreen, F3 Shortcut
functions and ASUS DRAM SPD (Serial Presence Detect) memory
information.
Manageability
WfM2.0, DMI3.0, WOL by PME, PXE
MAXIMUS IX HERO specifications summary
