Special Features
ASUS Dual Intelligent Processors 5
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU,
DIGI+ Power Control, Fan Xpert 3, and Turbo App
ASUS Exclusive Features
- AI Suite 3
- Disk Unlocker
ASUS EZ DIY
- USB BIOS Flashback
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS C.P.R.(CPU Parameter Recall)
- MemOK!
ASUS Q-Design
- Q-Code
- Q-Shield
- Q-Connector
- Q-LED (CPU [RED], DRAM [YELLOW], VGA [WHITE], Boot
Device LED [YELLOW GREEN]
- SafeSlot
- Q-DIMM
Software
Drivers
ROG GameFirst IV
ROG RAMDisk
ROG RamCache II
ROG CPU-Z
ROG Mem TweakIt
Overwolf
ROG Keybot II
Kaspersky
®
Anti-Virus
Daemon Tools Software
ASUS WebStorage
ASUS Utilities
Operating System
Support
Windows
®
10 64-bit
Windows
®
8.1 64-bit*
Windows
®
7*
* Windows
®
8.1 64-bit and Windows
®
7 32/64-bit are only supported when
using 6th Generation Intel
®
Processors
Form Factor
ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm)
Specications are subject to change without notice.
MAXIMUS IX HERO specifications summary
