Package contents
Check your motherboard package for the following items.
Motherboard ROG MAXIMUS IX HERO
Cables
2 x 2-in-1 SATA 6 Gb/s cables
1 x SLI HB BRIDGE(2-WAY-M)
Accessories
1 x I/O Shield
1 x Q-Connector
1 x ROG Coaster
1 x 10-in-1 ROG cable label
1 x CPU Installation Tool
1 x M.2 Screw Package
1 x ROG sticker
1 x 3D Printing Mount Screw Package
1 x Extension Cable for RGB Strips (80cm)
Application DVD ROG motherboard support DVD
Documentation User guide
If any of the above items is damaged or missing, contact your retailer.
