xi
(continued on the next page)
ROG Exclusive Features
Extreme Engine Digi+
- MicroFine Alloy Choke
- NexFET MOSFETs
- 10K Black Metallic Capacitors
Start Button
Reset Button
Safe Boot Button
Retry Button
BIOS Flashback Button
Clear CMOS Button
MemOK! Button
LN2 Mode
ROG RAMDisk
ROG CloneDrive
ROG RAMCache II
KeyBot II
- One-click overclocking
- X.M.P.
- DirectKey
- Clr CMOS
- Power On
UEFI BIOS features :
- Extreme Tweaker
- Tweakers’ Paradise
- ROG SSD Secure Erase
- GPU.DIMM Post
- O.C. Prole
- Graphics Card Information Preview
MAXIMUS IX HERO specifications summary
