xiv
Specications are subject to change without notice. Please refer to the ASUS website for
the latest specications.
MAXIMUS IX FORMULA specifications summary
BIOS
1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0,
SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash
3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control,
F3 My Favorites, Last Modied log, F12 PrintScreen, F3 Shortcut
functions and ASUS DRAM SPD (Serial Presence Detect) memory
information.
Manageability
WfM2.0, DMI3.0, WOL by PME, PXE
Operating System
Support
Windows
®
10 64-bit
Windows
®
8.1 64-bit*
Windows
®
7*
* Windows
®
8.1 64-bit and Windows
®
7 32/64-bit are only supported when
using 6th Generation Intel
®
Processors
Form Factor
ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm)
