1-30
Chapter 1: Product Introduction
Chapter 1
13. M.2 sockets (M.2_1; M.2_2)
ThesesocketsallowyoutoinstallM.2SSDmodules.
• WhentheM.2_1(Socket3)isoperatinginSATAmode,SATAport1(SATA6G_1)will
bedisabled.
• TheM.2SSDmoduleispurchasedseparately.
• M.2_1socketsupportsPCIe3.0x4andSATAmodeMKeydesignandtype2242/
2260/2280/22110PCIeandSATAstoragedevices.
• M.2_2socketsupportsPCIe3.0x4MKeydesignandtype2242/2260/2280PCIe
storagedevices.
• ThesesocketssupportIRST(Intel
®
RapidStorageTechnology).
• Intel
®
Optane™Technologyisonlysupportedwhenusing7thGenerationIntel
®
Optane™memorymodules,ensurethatyouhaveupdatedyourmotherboarddrivers
andBIOStothelatestversionfromtheASUSsupportwebsite.
