5
Your new oven
Here you will learn about your new oven. The control panel and
the individual operating controls are explained. You will find
information on the cooking compartment and the accessories.
Control panel
Here, you will see an overview of the control panel. Depending
on the appliance model, individual details may differ.
Buttons
Rotary selector
The rotary selector is used to alter the default values and set
values.
The rotary selector is retractable. Press on the rotary selector to
pop it in or out.
Display
The display goes into energy-saving mode shortly after the
appliance is switched off. The display darkens.
If you forget to switch off the hob after use, it will automatically
switch off after approximately 1 hour.
The display is divided into different sections:
■ Status bar
■ Progress display
■ Settings areas
■ Rotation direction indicator
Status bar
The status bar is located at the top of the display. It shows the
clock, the selected operating mode, instructions, information
and the time-setting options that have been set.
Progress display
The progress display provides you with a quick overview of the
cooking time as it counts down. It appears as a line under the
status bar after the cooking time starts. The line begins on the
left and becomes longer as the cooking time progresses. The
line reaches the right-hand extremity of the display once the
cooking time has elapsed.
Settings areas
The two settings areas show suggested values that you can
change. The settings area which is currently active has a light
background with black writing. You can make changes here.
You can use the
¾ and ¿ navigation buttons to switch from one
settings area to the next one. The
¾ and ¿ arrows in the
settings areas show you which way you can go with the
navigation buttons.
Once you start the oven, both settings areas are dark with light
writing.
RQ
RII
FOHDQ
VWDUW
VWRS
0
3
%XWWRQV
5RWDU\VHOHFWRU
%XWWRQV
'LVSOD\
Symbol Button function
‡
Switches the oven on and off
"
Selects the type of heating
X
Selects automatic programmes
l
Press and hold = selects the memory
Press briefly = starts the memory
s
Selects the cleaning system
This button is not assigned. The cleaning sys-
tem can only be selected when the self-cleaning
ceiling and side parts have been retrofitted and
connected, and the cleaning system has been
activated in the basic settings.
¾
Moves left within the control panel
¿
Moves right within the control panel
0
Opens and closes the time-setting options
@
Activates/deactivates the childproof lock
c
Switches on rapid heating
±
Press briefly = calls up information
Press and hold = opens or closes the Basic set-
tings menu
†
Press briefly = starts/pauses operation
Press and hold = cancels operation
&
7\SHVRIKHDWLQJ
6WDWXVEDU
3URJUHVVGLVSOD\
6HWWLQJVDUHD
DFWLYH
5RWDWLRQGLUHFWLRQLQGLFDWRU
6HWWLQJVDUHD
+RWDLUJULOOLQJ
