18
Detaching the door
1.Open the oven door fully.
2.Fold up the two locking levers on the left and right (figure A).
3.Close the oven door as far as the limit stop. With both hands,
grip the door on the left and right-hand sides. Close the door
a little further and pull it out (figure B).
Attaching the door
Reattach the oven door in the reverse sequence to removal.
1.When attaching the oven door, ensure that both hinges are
inserted straight into the opening (figure A).
2.The notch on the hinge must engage on both sides (figure B).
3.Fold back both locking levers (figure C). Close the oven
door.
: Risk of injury!
If the oven door falls out accidentally or a hinge snaps shut, do
not reach into the hinge. Call the aftersales service.
Removing and installing the door panels
To facilitate cleaning, you can remove the glass panels from the
oven door.
Removal
1.Detach the oven door and lay it on a cloth with the handle
facing down.
2.Unscrew the cover at the top of the oven door. To do this,
undo the left and right screws (fig. A).
3.Lift the top panel up and out (fig. B).
4.Unscrew the retaining clips on the right and left. Lift the panel
and remove the brackets from the panel (fig. C). Take out the
panel.
Clean the panels with glass cleaner and a soft cloth.
Do not use sharp or abrasive materials or a glass scraper. This
may damage the glass.
Fitting
When fitting, make sure that the lettering "right above" is upside
down at the bottom left.
1.Insert the panel diagonally towards the back (fig. A).
2.Stick the retaining clips onto the right and left-hand sides of
the panel, aligning them so that the carriers are over the
screw holes, and then screw in place (fig. B).
3.Insert the uppermost panel diagonally towards the back. The
smooth surface must face outwards.
4.Put the cover back in place and screw it on.
5.Attach the oven door.
Do not use the oven again until the panels have been
correctly fitted.
%
$
%
$
&
%
$
&
%
$
