Before using your washer dryer for the first time Preparing your washer dryer Attention The washer dryer must have been installed and connected properly refer to page 54 EE The washer dryer was tested before leaving the factory To remove any water left over from testing procedures the first washing cycle should be carried out without laundry in the machine Turn the tap on Pull out the detergent drawer all the way Pour approx 1 litre of water into chamber II of the detergent dispenser Half fill the measuring beaker with detergent and pour into chamber II EE Do not use any special detergents for delicates or woollens excessive foam Close the detergent drawer Close the washer dryer door Set the programme selector to Cottons 90 C Touch the Start Pause O button The programme starts The programme ends when all symbols in the upper row of the display field go out the progress bar is completely filled and the programme duration is on 0 Turn the programme selector to o Off 13
