Loading the laundry Risk of explosion Items of clothing that have been pretreated with solvent based cleaning agents e g stain remover and dry cleaning spirit represent an explosion hazard once loaded into the washer dryer Before loading the laundry rinse thoroughly by hand Attention Foreign objects in the drum may damage the laundry Before loading the laundry check that there is no debris in the drum Open the washer dryer door Unfold the sorted items of clothing and place them loosely into the drum Mix large and small items Laundry items which vary in size are more evenly distributed during the spin cycle T Do not exceed recommended loads Overloading will cause poor wash results and encourage creasing Close the washer dryer door Take care not to trap any items of clothing between the loading door and rubber seal 19
