If the water pressure is low the symbol illuminates If required deactivate the childproof lock Select an additional programme Empty Spin or touch the Start Pause 0 button directly If required activate the childproof lock At the end of the additional programme If required deactivate the childproof lock Turn the programme selector to O Off Removing the laundry Open the washer dryer door If the loading door cannot be opened Wait 2 minutes safety function is active or there is still water in the washer dryer if the without final spin option was selected Select the Empty or Spin programme and touch the Start Pause O button Unload the laundry Attention Remove any foreign objects e g coins paper clips from the drum and rubber seal risk of rust Leave the washer dryer door and detergent drawer open to allow the interior of the washer dryer to dry After drying Take the laundry out of the machine immediately to prevent creasing This is particularly import with synthetic fabrics Cottons Linens Cotton and linen items which have been dried to iron dry should be rolled together to prevent them from drying out completely before they are ironed Cupboard dry items must be smoothed out and folded up Easy care synthetics Hang shirts and blouses individually on hangers 40
