Programmes and functions Programme selector Washing programmes Select the desired programme EE Programmes wash lightly soiled textiles in the shortest possible time For heavily soiled textiles reduce the load or touch the Intensive B button Cottons îî cold 90 C Cottons Eco 6 cold 60 C Hard wearing textiles heat resistant textiles made of cotton or linen Cottons Eco 660 C Intensive B For stained heavily soiled textiles e g cotton or linen Energy and water saving programme The longer washing time in this 60 C programme means that the cleaning effects are comparable with those of a 90 C programme although the power and water consumption is considerably lower Cottons t 90 C Energy intensive programme for heat resistant textiles e g made of cotton or linen To protect the waste water pipes the hot water is mixed with approx 7 litres of cold water and cooled before being drained Delicate Silk Ü cold 30 C For delicate washable textiles e g silk satin synthetic materials or blended fabrics e g curtains Delicates cycle at 30 C for hand and machine washable silk EE We do not recommend washing these textiles with other rougher textiles No spin between the rinse cycles Reduced spin speed Wool g cold 40 C Hand and machine washable wool or wool rich textiles e g cashmere mohair or angora Also suited for hand washable silk 22
