You can change the default washing temperature Washing temperature Keep touching the temperature button C until the desired temperature displays 0 For different clothing there are different W r programmes with respective temperature ranges 2 5k MD L BOD w a c 050 5U L8UU 0 Spin speed You can change the default spin speed Touch the button until desired spin speed displays 0 If setting without final spin has been selected the washing remains in the final rinsing water Before the laundry can be uplaoded the Empty or Spin programme must be performed Touch button to select the desired spin speed or touch the Start Pause i button directly to start subsequent spin cycle with default spin speed 0 The speed can be changed at any time by touching the button until the new speed is displayed Setting without final spin is possible until the Rinse programme section starts 32
