Finish in time Before a programme starts you can specify by how many hours later the programme is to be ended Example of Easy Care 40 C programme Touch the button the display shows the minimum finish in time of the selected programme Such as 1h i e 1 hour EE The minimum finish in time of different programmes are different It depends on the duration of selected programme W a 0 5 kg HO E 8D0 PHh Touch the button until the desired number of hours is displayed EE The finish in time can be set in 1 hour steps The time can be delayed up to a maximum of 24h If a finish in time of 24h has been set the programme duration mode can be accessed by touching the button again You can change other settings or Touch the Start Pause i button The finish in time starts counting down The first segment of the progress bar flashes EE The finish in time is counted down by the hour When the finish in time has elapsed the programme starts automatically and the programme duration is displayed EE Changes to the finish in time or an immediate start are possible To do this Touch the Start Pause i button The programme duration time appears Touch the Start Pause i button directly to start the programme immediately If required reset the finish in time touch the Start Pause button 33
