Washing drying with standard settings Your washer dryer can be used in three ways washing only drying only washing and drying without a break in between S For uninterrupted washing and drying the maxi mum load must be reduce to 2 5 kg for cottons coloureds or 1 5 kg for easy care EE TO achieve good washing drying result for terry towel the recommended load is 4 0 kg for was hing and 2 0 kg for drying The specified standard settings to the selected programme are optimally If you do not want to change these standard settings Washing Example of Easy Care 40 C programme Turn on the tap Turn the programme selector to the desired programme Start Pause indicator light flashes w a C D BDD 050 The following is displayed for the selected programme progress bar default rinse cycle s maximum load do not exceed max load default washing temperature default spin speed 28 adjusted
