Siemens WD12D520 [37/63] During washing drying
![Siemens WD12D520 [37/63] During washing drying](/views2/1028677/page37/bg25.png)
q
q
q
q
q
q
“” (without final spin
i
q
q
q
q
q
q =
Содержание
- Operating and installation instructions 1
- Siemens 1
- Installation instructions 2
- Operating instructions 2
- Table of contents 2
- A danger of death 4
- A risk of choking 4
- Appliances 4
- Disposing of the 4
- Disposing of your 4
- Information concerning waste disposal 4
- Old appliance 4
- Packaging 4
- Packaging and old 4
- Cottons eco 6 60 c 5
- Cottons îî 90 c 5
- Hints and tips 5
- Intensive 5
- Protection of the environment i hints and tips 5
- General safety instructions 6
- Adding detergent cleaning product 7
- Introducing your washer dryer 7
- Opening and closing the door service flap 7
- Control panel 8
- Display panel 8
- Extra rinse 8
- Intensive 8
- Pre wash 8
- Programme selector 8
- Start pause 8
- Touch buttons for additional options 8
- A x 5 kg 9
- Display 9
- Display panel 9
- Rnor inn qi 1 tn inn u llcliunu u iqu 9
- Display 10
- Low water pressure 10
- Other displays at this location 10
- Programme status display 10
- O childproof lock 11
- Programme duration 11
- Recommended load 11
- Spin speed 11
- W overdosage 11
- Washing temperature 11
- Drying duration or automatic drying 12
- Extra rinse 12
- Finish in time 12
- Increases in time 12
- Intensive 12
- Reductions in time 12
- W 2 rinse cycles 12
- Attention 13
- Before using your washer dryer for the first time 13
- Cottons 90 13
- Preparing your washer dryer 13
- Start pause 13
- Without 13
- Preparing laundry for drying 14
- Preparing sorting and loading the laundry 14
- Preparing the laundry 14
- According to colour and degree of dirt 15
- Attention 15
- Degrees of dirt 15
- Sorting the laundry 15
- Ughtly soiled 15
- Normally soiled 16
- Typical stains 16
- Very soiled 16
- Following care symbols 17
- Only wash laundry that is labelled with the 17
- Removing stains 17
- Sorting laundry according to the instructions on the care labels 17
- W w w w 17
- W w w w w 17
- X w w w w 17
- Care symbols 18
- Dangerous vapors 18
- Explosion hazard 18
- Only dry laundry that is labelled with the following 18
- Risk of creasing 18
- Risk of shrinking 18
- Waste of energy 18
- Attention 19
- Loading the laundry 19
- Risk of explosion 19
- Detergents and cleaning products 20
- Dosing detergent 20
- Adding detergent cleaning product 21
- Cottons 22
- Cottons eco 22
- Cottons îî cold 90 c cottons eco 6 cold 60 c 22
- Delicate silk ü cold 30 c 22
- Intensive 22
- Programme selector 22
- Programmes and functions 22
- Washing programmes 22
- Wool g cold 40 c 22
- Easy care cold 60 c 23
- Easy care plus cold 40 c 23
- Mix 0 cold 40 c 23
- Outdoor 23
- Shirts business cold 60 c 23
- Super 15 o cold 40 c 23
- V cold 40 c 23
- Automatic drying 24
- Drying programmes 24
- Fine adjustment 24
- Gentle dry ft 24
- Intensive dry 24
- Cottons coloureds cotton linen 25
- Cupboard dry 25
- Dry iron dry 25
- Dry weight in kg 25
- Easy care 25
- Easy care synthetics 25
- Gentle dry acrylics 25
- Guide values for drying times 25
- Intensive 25
- Time controlled drying 25
- Extra rinse 26
- Programme options rinse 26
- Additional options buttons 27
- Amount of programme and degree of 27
- Extra rinse 27
- Intensive 27
- Laundry intensive button w soiling 27
- Prewash 1 27
- Super 15 27
- Wool outdoor 27
- Bdd 050 28
- Washing 28
- Washing drying with standard settings 28
- Drying 29
- Gentle dry 29
- Intensive dry 29
- Rutq 00 29
- Washing drying without interruption 30
- Overview at a glance 31
- Washing drying with individual settings 31
- Md l bod 050 32
- Spin speed 32
- Washing temperature 32
- Easy care 40 c 33
- Finish in time 33
- Ho e 8d0 phh 33
- Start pause 33
- Cancelling the programme 34
- Changing the programme 34
- Activating the childproof lock 35
- Childproof lock 35
- Deactivating the childproof lock 35
- Easy care 40 c 35
- Start pause 35
- Signal 36
- Start the signal mode 36
- Ô1 îfl 36
- Cancelling the 37
- Changing the 37
- During washing drying 37
- Programme 37
- Pausing the programme 38
- Setting without final spin selected 39
- Unor nnn ___ ____ _ n_ 39
- When the programme has ended 39
- After drying 40
- Attention 40
- Cottons linens 40
- Cupboard dry 40
- Easy care synthetics 40
- Empty spin 40
- Iron dry 40
- Removing the laundry 40
- Risk of rust 40
- Start pause 40
- Cottons 41
- Soaking 41
- Special applications 41
- Starching 41
- Start pause 41
- Attention 42
- Bleaching 42
- Cottons 42
- Dyeing 42
- A risk of electric shock 43
- A risk of explosion 43
- Clean housing fascia and supply lines 43
- Cleaning and care 43
- Cleaning the drum 43
- Cleaning the deter gentdispenser 44
- A risk of scalding 45
- Cleaning the drain pump 45
- Drain the water 45
- Cleaning the strainer at the water tap 46
- Cleaning the strainer on the washer dryer 46
- Cleaning water inlet strainers 46
- Spin empty 46
- Start pause 46
- Descaling the washer dryer 47
- A risk of electric shock 48
- Fault displays 48
- Help with minor problems 48
- Possible cause remedial action 48
- Text in display field and signal emitted 48
- Problems cause remedial action 50
- Display field programme duration 51
- Problems cause remedial action 51
- Consumption values 52
- Cottons 40 c 52
- Cottons 60 c 52
- Cottons 90 c 52
- Cottons eco 60 c intensive intensive 52
- Cottons eco 60 c intensive œ 52
- Delicate silk 0 30 c 52
- Dry 2 auto drying cycles œ 52
- Easy care 40 c 52
- Easy care plus 30 c 52
- Gentle dry 3 52
- Intensive 52
- Intensive dry 52
- Load consumption values programme duration power water 52
- Mix 40 c 52
- Normal programme additional option 52
- Outdoor 30 c 52
- Shirts blouses 40 c 52
- Super 15 30 c 52
- Wool g 30 c 52
- Customer service 53
- E nr fd 53
- Product number production number 53
- Installing connecting and transporting 54
- Safety instructions 54
- Standard accessories 54
- Dimensions 55
- Installation surface 55
- Useful tools 55
- Removing the transportation pro tection devices 56
- Attention 57
- Built under or built in appliance installation 57
- Hose and cable lengths 58
- Attention 59
- Connecting the water 59
- Risk of electric shock 59
- Water inlet hose 59
- Aligning the washer dryer 60
- Attention 60
- Water drainage hose warning 60
- Caution 61
- Connecting the power 61
- Preparing and inserting the transport bolts 62
- Transport e g when moving 62
Похожие устройства
- Akai 14CTN51BG Инструкция по эксплуатации
- Moulinex OW200033 Инструкция по эксплуатации
- Diam SМ-800/2.2 600026 Инструкция по эксплуатации
- Rolsen RL-20X30 Инструкция по эксплуатации
- Siemens WM10E363 Инструкция по эксплуатации
- Fubag A-100KM Инструкция по эксплуатации
- Akai 14CTN50BS Инструкция по эксплуатации
- Moulinex OW301030 Инструкция по эксплуатации
- Olympus C-720 Ultra Zoom Инструкция по эксплуатации
- Siemens WM12E464 Инструкция по эксплуатации
- Зубр ЗАС-140 Инструкция по эксплуатации
- Akai 14CTN50BG Инструкция по эксплуатации
- Moulinex OW500230 Инструкция по эксплуатации
- Vitek VT-1744 Инструкция по эксплуатации
- Siemens WM10E164 Инструкция по эксплуатации
- Akai 21CTS65BS Инструкция по эксплуатации
- Хайтек MBSA100 Инструкция по эксплуатации
- Moulinex ME41113E Инструкция по эксплуатации
- Yamaha DVD-S530 Инструкция по эксплуатации
- Akai 29CTF66BC Инструкция по эксплуатации
During washing drying Changing the programme If you have accidentally selected the wrong programme If the childproof lock is active temporarily deactivate see page 35 Turn the programme selector to a newly selected programme If required change other settings Cancelling the programme Touch starts the Start Pause i If required re activate see page 35 the button The childproof programme lock If you would like to terminate a programme and remove the laundry If the childproof lock is active deactivate see page 35 Turn the programme selector to Empty v Spin or Rinse w If required select the desired spin speed but not setting without final spin EE If a programme is interrupted at a high temperatu re Rinse w should be selected to cool down the laundry For drying programme select time dry 15 min cooling programm to cool down the laundry Touch the Start Pause button If required switch on the childproof lock again Wait until programme ends Deactivate the childproof lock Turn the programme selector to O Off 37
