Problems Cause Remedial action Washer dryer door cannot be opened There is still some water in the appliance without final spin selected Select Empty or Spin Safety function is active Wait for 2 minutes Damp or lumpy detergent Clean and dry the detergent dispenser see page 44 Detergent residue in the detergent drawer Use the dosing aid for liquid detergent Difficutt to dissolve detergent tablets used Before filling dispenser II crush the tablets in the packet Odour in the appliance Washing at mainly low temperatures and or with liquid detergents Run the Cottons 90 C programme without washing Use a standard detergent Control lights do not come on A fuse has triggered Switch on replace the fuse If the fault occurs repeatedly call Customer Service Power failure An interrupted programme will be resumed when the power returns If you wish to unload the laundry proceed as in Cleaning the drain pump page 45 Plug is loose or not plugged in Programme does not start Loading door not closed properly Check whether laundry is trapped in door Close the loading door a click should be heard Water does not enter the machine or detergent is not washed away Detergent in chamber 1 is not washed away Start Pause O button not touched Touch the Start Pause O button Tap not turned on Turn the tap on Inlet hose kinked or pinched Filter blocked in water inlet hose Clean the strainer see from page 46 A programme without Pre wash 1 was selected Select additional function Prewash 1 49
