Package contents

Check your motherboard package for the following items.

Motherboard ROG STRIX Z370-G GAMING

Cables

4 x SATA 6Gb/s cables

1 x SLI HB BRIDGE (2-WAY-S)

1 x Thermal sensor cable

Accessories

1 x I/O shield

1 x CPU Installation tool

1 x Cable ties pack(s)

1 x MB CABLEMOD COUPON

1 x STRIX DOOR HANGER

1 x M.2 screws Package

1 x STRIX Series sticker

1 x Vertical M.2 bracket set

Application drive ROG motherboard support DVD

Documentation User guide

If any of the above items is damaged or missing, contact your retailer.
