ASUS ROG STRIX Z370-G GAMING
1-13
Chapter 1
4. USB 3.1 Gen1 connectors (20-1 pin U31G1_34)
TheseconnectorsallowyoutoconnectaUSB3.1Gen1moduleforadditionalUSB3.1
Gen1frontorrearpanelports.WithaninstalledUSB3.1Gen1module,youcanenjoy
allthebenetsofUSB3.1Gen1includingfasterdatatransferspeedsofupto5Gb/s,
fasterchargingtimeforUSB-chargeabledevices,optimizedpowerefciency,and
backwardcompatibilitywithUSB2.0.
TheUSB3.1Gen1moduleispurchasedseparately.
®
ROG STRIX Z370-G GAMING USB 3.1 Gen 1 connector
U31G1_34
PIN 1
GND
IntA_P1_D+
IntA_P1_D-
GND
IntA_P1_SSTX+
IntA_P1_SSTX-
GND
IntA_P1_SSRX+
IntA_P1_SSRX-
Vbus
IntA_P2_D+
IntA_P2_D-
GND
IntA_P2_SSTX+
IntA_P2_SSTX-
GND
IntA_P2_SSRX+
IntA_P2_SSRX-
Vbus
DONOTconnecta1394cabletotheUSBconnectors.Doingsowilldamagethe
motherboard!
TheUSB2.0moduleispurchasedseparately.
5. USB 2.0 connectors (10-1 pin USB1112, USB1314)
TheseconnectorsareforUSB2.0ports.ConnecttheUSBmodulecabletothese
connectors,theninstallthemoduletoaslotopeningatthebackofthesystemchassis.
ThisUSBconnectorcomplieswithUSB2.0specicationthatsupportsupto480Mb/s
connectionspeed.
®
ROG STRIX Z370-G GAMING USB2.0 connectors
USB+5V
USB_P14-
USB_P14+
GND
NC
USB+5V
USB_P13-
USB_P13+
GND
USB1314
PIN 1
USB+5V
USB_P12-
USB_P12+
GND
NC
USB+5V
USB_P11-
USB_P11+
GND
USB1112
PIN 1
