3-18

Chapter 3: BIOS Setup

Chapter 3

3.6.7 Onboard Devices Configuration

The items in this menu allow you to switch between PCIe Lanes and congure onboard

devices.

Hyper M.2X16 [Enabled][Disabled]

[Disabled] Only one SSD installed onto the Hyper M.2 X16 card can be detected.

[Enabled] Two or three SSDs installed onto the Hyper M.2 X16 card can be detected.

The number of SSDs that can be detected varies with the congurations of the PCIe X16

slots.

HD Audio Controller

This item allows you to use the Azalia High Denition Audio Controller.

Conguration options: [Disabled] [Enabled]

M.2_1 Configuration: [Auto][SATA mode][PCIE mode]

[Auto] Auto-detects the M.2 device mode. If a SATA device is detected,

SATA6G_1 will be disabled.

[SATA mode] Only supports M.2 SATA devices. Please note that SATA6G_1 port cannot

be used in this mode.

[PCIE mode] Only supports M.2 PCIE devices.

Intel LAN Controller

This item allows you to enable or disable the Intel LAN controllers.

Conguration options: [Disabled] [Enabled]

3.6.8 APM Configuration

The items in this menu allow you to set system wake and sleep settings.

ErP Ready

This item allows you to switch off some power at S4+S5 or S5 to get the system ready for

ErP requirement. When set to [Enabled], all other PME options are switched off.

Conguration options: [Disabled] [Enable(S4+S5)] [Enable(S5)]

3.6.9 Network Stack Configuration

The items in this menu allow you to congure Ipv4 / Ipv6 PXE support.

3.6.10 HDD/SSD SMART Information

The items in this menu display the SMART information of the connected devices.

NVM Express devices do not support SMART information.

3.6.6 PCH-FW Configuration

This item allows you to congure the rmware TPM.
