1-14
Chapter 1: Product Introduction
Chapter 1
6. CPU, CPU optional, W_PUMP+, and chassis fan connectors (4-pin CPU_FAN;
4-pin CPU_OPT; 4-pin W_PUMP+, 4-pin CHA_FAN1-2)
Connectthefancablestothefanconnectorsonthemotherboard,ensuringthatthe
blackwireofeachcablematchesthegroundpinoftheconnector.
• DONOTforgettoconnectthefancablestothefanconnectors.Insufcientairow
insidethesystemmaydamagethemotherboardcomponents.Thesearenotjumpers!
Donotplacejumpercapsonthefanconnectors!
• EnsurethattheCPUfancableissecurelyinstalledtotheCPUfanconnector.
A
B
C
D
E
CHA_FAN2
E
CHA FAN PWM
CHA FAN IN
CHA FAN PWR
GND
CPU_FAN
A
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
W_PUMP+
D
PUMP PWM
PUMP IN
PUMP PWR
GND
CPU_OPT
C
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
CHA_FAN1
B
CHA FAN PWM
CHA FAN IN
CHA FAN PWR
GND
®
ROG STRIX Z370-G GAMING Fan connectors
• TheCPU_FANconnectorsupportstheCPUfanofmaximum1A(12W)fanpower.
• ConnectthefanofyourwatercoolingkittotheW_PUMP+connector.
7. Thermal sensor connector (2-pin T_SENSOR1)
Thisconnectorisforthethermistorcablethatmonitorsthetemperatureofthedevices
andthecriticalcomponentsinsidethemotherboard.Connectthethermistorcable
andplacethesensoronthedeviceorthemotherboard’scomponenttodetectits
temperature.
PIN 1
T_SENSOR
SENSOR IN
GND
®
ROG STRIX Z370-G GAMING T_SENSOR connector
