Asus ROG CROSSHAIR VI EXTREME [23/108] Expansion slots
![Asus ROG CROSSHAIR VI EXTREME [23/108] Expansion slots](/views2/1307911/page23/bg17.png)
ROG CROSSHAIR VI EXTREME
1-7
Chapter 1
1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
causeyouphysicalinjuryanddamagemotherboardcomponents.
Slot No. Slot Description
1 PCIe2.0x1_1slot
2 PCIe3.0x16/x8_1slot
3 PCIe2.0x1_2slot
4 PCIe3.0x8_2slot
5 PCIe2.0x1_3slot
6 PCIe2.0x4_3slot
