11
HSE
Higher SEt. Maximum possible setpoint value
-50…230
10
1&2
°C/°F
LSE
Lower SEt. Minimum possible setpoint value
-55…99
0
1&2
°C/°F
OSP
Offset Set Point. Temperature Value to be added to the Set-Point if reduced set is
enabled (Economy function).
-30…30
0
2
°C/°F
HC
digital (input) Open door. Digital input that allow you to switch off loads. Valid if H11 = ±4
(door switch). n = does not switch off loads; y = switch off loads.
h/c
c
2
flag
dOd
digital (input) Open door. Ingresso digitale che permette di spegnere le utenze.
Valido se H11 = ±4 (micro porta). n = non spegne le utenze; y = spegne le utenze.
n/y
n
2
flag
dAd
digital (input) Activation delay. Delay time in activating the digital input.
0…255
0
2
min
Ont
ON time (compressor). Compressor activation time in the event of faulty probe. If OFt=1
and Ont=0, the compressor is always off, while if OFt=1 and Ont>0 it operated in duty
cycle mode.
0...250
6
2
min
OFt
OFF time (compressor). Compressor deactivation time if probe is faulty. If Ont=1 and
OFt=0, the compressor is always on, while if Ont=1 and OFt>0 it operated in duty cycle
mode.
0...250
6
2
min
dOn
delay (at) On compressor. Delay time in activating the compressor relay after switch-on
of instrument.
0...250
0
2
secs
dOF
delay (after power) OFF. Delay after switch off; the indicated time must elapse between
switch-off of the compressor relay and the successive switch-on.
0...250
3
2
min
dbi
delay between power-on. Delay between switch-ons; the indicated time must elapse
between two successive switch-ons of the compressor.
0...250
5
2
min
OdO
delay Output (from power) On. Delay time in activating the outputs after switch-on of the
instrument or after a power failure.
0...250
0
2
min
DEFROST
dit
defrost interval time. Interval between the start of two successive defrosting operations.
0...250
6
1&2
hours
dCt
defrost Counting type. Selection of count mode for the defrosting interval.
0 = compressor operating hours (DIGIFROST® method);
Defrosting active only if compressor is on;
1 = Real Time - equipment operating hours; defrost counting is always active when the
machine is on and start everytime the instrument switch on;
2 = compressor stop. Each time the compressor stops a defrosting cycle is performed
according to parameter dtY.
0/1/2
1
2
num
dOH
defrost Offset Hour. Start-of-defrosting delay time from the call.
0...59
0
2
min
dEt
defrost Endurance time. Defrosting time-out; determines duration of defrosting.
1...250
20
1&2
min
dPO
defrost (at) Power On. Determines if at the start-up the instrument must enter defrosting
(if the temperature measured by the evaporator allows this operation). y = yes; n = no.
n/y
n
2
flag
ALARMS
Att
Allow you to select if the parameters HAL and LAL will have absolute (Att=0) or relative
(Att=1) value.
0/1
1
2
flag
AFd
Alarm Fan differential. Alarm differential.
1…50
2
2
°C/°F
HAL
Higher ALarm. Maximum temperature alarm. Temperature value (in relative value) which
if exceeded in an upward direction triggers the activation of the alarm signal.
-50…150
15
1&2
°C/°F
LAL
Lower ALarm. Minimum temperature alarm. Temperature value (in relative value), which
if exceeded in a downward direction, triggers the activation of the alarm signal.
-50…50
-2
1&2
°C/°F
PAO
Power-on Alarm Override. Alarm exclusion time after instrument switch on, after a power
failure.
0…10
2
2
hours
dAO
defrost Alarm Override. Temperature alarm exclusion time after defrost.
0…999
60
2
min
OAO
Alarm signaling delay after digital input disabling (door close). Alarm is only for high-low
temperature alarms.
0…10
0
2
hours
tdO
time out door Open. Alarm activation delay time open door.
0…250
0
2
min
tAO
temperature Alarm Override. Temperature alarm signal delay time.
0…250
15
1&2
min
EAL
External Alarm Clock. External alarm to lock loads (n = don’t lock loads; y = lock loads).
n/y
n
2
flag
COMMUNICATION
dEA
Device address in family (valid values from 0 to 14).
0…14
0
2
num
FAA
Device family (valid values from 0 to 14). The FAA and dEA values represent the network
address of the equipment and are indicated in the following format “FF.DD” (where
FF=FAA and DD=dEA).
0…14
0
2
num
DISPLAY
LOC
LOCk. Setpoint change shutdown. See related paragraph. There is still the possibility to
enter into parameters programming and modify these, including the status of this
parameter to permit keyboard shutdown. n = no; y = yes.
n/y
n
1&2
flag
PS1
PAssword 1. When enabled (value ≠ 0) it constitutes the access key for level 1
parameters.
0...250
0
1&2
num
PS2
PAssword 2. When enabled (value ≠ 0) it constitutes the access key for level 2
parameters.
0...250
15
2
num
ndt
number display type. View with decimal point. y = yes; n = no.
n/y
n
2
flag
CA1
CAlibration 1. Positive or negative temperature value added to the value read by probe 1.
-12.0...12.0
-1
1&2
°C/°F
ddL
efrost display Lock. Viewing mode during defrosting.
0 = shows the temperature read by the room probe;
1 = locks the reading on the temperature value read by room probe when defrosting
starts, and until the next time the Setpoint value is reached;
2 = displays the label “dEF” during defrosting, and until the next time the Setpoint value is
reached.
0/1/2
1
1&2
num
dro
display read-out. Select °C or °F for displaying the temperature read by the thermostat
probe.(0 = °C, 1 = °F).
PLEASE NOTE: the switch between °C and °F DO NOT modify setpoint, differential,
etc. (for example set=10°C become 10°F)
0/1
0
2
flag
ddd
Selection of type of value to be displayed.
0 = Setpoint; 1 = cold room probe (Pb1); 2 = evaporator probe (Pb2)
0/1/2
1
2
num
CONFIGURATION
H08
Stand-by operating mode.
0 = display switch off;
1 = display switch off, loads and alarms stopped;
2 = display with OFF label, loads and alarms stopped.
0/1/2
2
2
num
