104
CODE No. list (Example)
*1 The initial setup value of EEPROM installed on the service P.C. board
*2 <Model Name: MMU-AP ∗∗∗ 2H>
For the above models, set CODE No. to “ ” and the setting data 0000 (initial) to “0001”.
CODE No. (DN) Item Setting data Factory-set value
01
Filter sign lighting time Depending on Type
02
Filter pollution leve 0000: standard
03
Central control address 0099: Not determined
06
Heating suction temperature shift 0002: +2 °C (Floor standing type: 0)
0d
Existence of automatic COOL/HEAT mode
0001: No auto mode cooling / heating
* Automatically selection
by connected outdoor
unit
0F
Cooling only 0000: Heat pump
10
Type Depending on model type
11
Indoor unit capacity Depending on capacity type
12
System address 0099: Not determined
13
Indoor unit address 0099: Not determined
14
Group address 0099: Not determined
19
Louver type (wind direction adjustment) Depending on Type.
1E
Temperature range of cooling / heating
automatic SW control point
0003: 3 deg (Ts ± 1.5)
28
Power failure automatic recovery 0000: None
31
Vent Fan (Single operation) 0000: Not possible
32
Sensor SW (Selection of static pressure) 0000: Body sensor
5d
High ceiling select 0000: Standard
60
Timer setting (wired remote controller) 0000: Available
F0
Swing mode 0001: Standard
D0
Power save operation 0001: Standard
Type
Code No. [10]
Setup data Type Model abb. name
0000 1-way Cassette MMU-AP∗∗∗SH
0001 *1, *2 4-way Cassette MMU-AP∗∗∗2H
0002 2-way Cassette MMU-AP∗∗∗WH
0003
1-way Cassette
(Compact type)
MMU-AP∗∗∗YH
0004 Concealed Duct Standard MMD-AP∗∗∗BH
0005
Slim Duct MMD-AP∗∗∗SPH
MMD-AP∗∗∗SH
0006 Concealed Duct High Static Pressure MMD-AP∗∗∗H
0007 Ceiling MMC-AP∗∗∗H
0008 High Wall MMK-AP∗∗∗H
0009 — —
0010 Floor Standing Cabinet MML-AP∗∗∗H
0011 Floor Standing Concealed MML-AP∗∗∗BH
0012 — —
0013 Floor Standing MMF-AP∗∗∗H
0014 Compact 4-way Cassette MMU-AP∗∗∗MH
0016 Fresh air intake unit (Duct type) MMD-AP∗∗∗HFE
Indoor unit capacity
CODE No. [11]
Setup data Model Setup data Model
0000* Invalid 0016 —
0001 007 type 0017 048 type
0002 — 0018 056 type
0003 009 type 0019 —
0004 — 0020 —
0005 012 type 0021 072 type
0006 — 0022 —
0007 015 type 0023 096 type
0008 — 0024 —
0009 018 type 0025 —
0010 — 0026 —
0011 024 type 0027 —
0012 027 type 0028 —
0013 030 type ~ —
0014 — 0034 —
0015 036 type
