50
Type
DN code “10”
*1 Default value stored in EEPROM mounted on service P.C. board
Indoor Unit Capacity
DN code “11”
*1 Default value stored in EEPROM mounted on service P.C. board
Value Type Model
0000 1-way Cassette MMU-AP∗∗∗SH
0001*
1
4-way Cassette MMU-AP∗∗∗H
0002 2-way Cassette MMU-AP∗∗∗WH
0003 1-way Cassette (Compact) MMU-AP∗∗∗YH
0004 Concealed Duct Standard MMD-AP∗∗∗BH
0005 Slim Duct MMD-AP∗∗∗SPH (SH)
0006 Concealed Duct High Static Pressure MMD-AP∗∗∗H
0007 Ceiling MMC-AP∗∗∗H
0008 High Wall MMK-AP∗∗∗H
0010 Floor Standing Cabinet MML-AP∗∗∗H
0011 Floor Standing Concealed MML-AP∗∗∗BH
0013 Floor Standing MMF-AP∗∗∗H
0014 Compact 4-way Cassette MMU-AP∗∗∗MH
0016 Fresh Air Intake indoor unit (Duct type) MMD-AP∗∗∗HFE
Value Capacity
0000* Invalid
0001 007 type
0003 009 type
0005 012 type
0007 015 type
0009 018 type
0011 024 type
0012 027 type
0013 030 type
0015 036 type
0017 048 type
0018 056 type
0021 072 type
0023 096 type
~–
