12
Specifications
Model
Sound power level (dBA) Weight (kg)
Cooling Heating Main unit (Ceiling panel)
MMU-AP0074MH-E * * 17 (3)
MMU-AP0094MH-E * * 17 (3)
MMU-AP0124MH-E * * 17 (3)
MMU-AP0154MH-E * * 17 (3)
MMU-AP0184MH-E * * 17 (3)
MMU-AP0074YH-E * * 22 (3.5)
MMU-AP0094YH-E * * 22 (3.5)
MMU-AP0124YH-E * * 22 (3.5)
MMU-AP0154SH-E * * 21 (5.5)
MMU-AP0184SH-E * * 21 (5.5)
MMU-AP0244SH-E * * 22 (5.5)
MMD-AP0074BH-E * * 28
MMD-AP0094BH-E * * 28
MMD-AP0124BH-E * * 28
MMD-AP0154BH-E * * 32
MMD-AP0184BH-E * * 32
MMD-AP0244BH-E * * 43
MMD-AP0274BH-E * * 43
MMD-AP0304BH-E * * 43
MMD-AP0364BH-E * * 55
MMD-AP0484BH-E * * 55
MMD-AP0564BH-E * * 55
MMD-AP0184H-E * * 50
MMD-AP0244H-E * * 52
MMD-AP0274H-E * * 52
MMD-AP0364H-E * * 56
MMD-AP0484H-E * * 67
MMD-AP0724H-E * * 160
MMD-AP0964H-E 70 70 160
MMD-AP0074SPH-E * * 22
MMD-AP0094SPH-E * * 22
MMD-AP0124SPH-E * * 22
MMD-AP0154SPH-E * * 23
MMD-AP0184SPH-E * * 23
MMC-AP0154H-E * * 22
MMC-AP0184H-E * * 22
MMC-AP0244H-E * * 26
MMC-AP0274H-E * * 26
MMC-AP0364H-E * * 34
MMC-AP0484H-E * * 34
MML-AP0074H-E * * 37
MML-AP0094H-E * * 37
MML-AP0124H-E * * 37
MML-AP0154H-E * * 37
MML-AP0184H-E * * 40
MML-AP0244H-E * * 40
MML-AP0074BH-E * * 21
MML-AP0094BH-E * * 21
MML-AP0124BH-E * * 21
MML-AP0154BH-E * * 29
MML-AP0184BH-E * * 29
MML-AP0244BH-E * * 29
MMF-AP0154H-E * * 48
MMF-AP0184H-E * * 48
MMF-AP0244H-E * * 49
MMF-AP0274H-E * * 49
MMF-AP0364H-E * * 65
MMF-AP0484H-E 72 72 65
MMF-AP0564H-E 72 72 65
