Location No. Part No. Description
MMD-
AP0074BH-
E(TR)
AP0094BH-
E(TR)
AP0124BH-
E(TR)
AP0154BH-
E(TR)
AP0184BH-
E(TR)
401 43050425 SENSOR ASSY, SERVICE, TC 2 2 2 2 2
402 43050426 SENSOR, SERVICE, TA 1 1 1 1 1
403 43150320 SENSOR ASSY, SERVICE, TG 1 1 1 1 1
404 43158193 REACTOR, CH-43-2Z-T 1 1 1 1 1
405 43160575 TERMINAL BLOCK, 2P, 20A 1 1 1 1 1
406 4316V438 P.C. BOARD ASSY, MCC-1402 1 1 1 1 1
407 43160582 TERMINAL, 4P 1 1 1 1 1
Location No. Part No. Description
MMD-
AP0244BH-
E(TR)
AP0274BH-
E(TR)
AP0304BH-
E(TR)
AP0364BH-
E(TR)
AP0484BH-
E(TR)
401 43050425 SENSOR ASSY, SERVICE, TC 2 2222
402 43050426 SENSOR, SERVICE, TA 1 1111
403 43150320 SENSOR ASSY, SERVICE, TG 1 1111
404 43158193 REACTOR, CH-43-2Z-T 1 1111
405 43160575 TERMINAL BLOCK, 2P, 20A 1 1111
406 4316V438 P.C. BOARD ASSY, MCC-1402 1 1111
407 43160582 TERMINAL, 4P 1 1111
Location No. Part No. Description
MMD-
AP0564BH-E(TR)
401 43050425 SENSOR ASSY, SERVICE, TC 2
402 43050426 SENSOR, SERVICE, TA 1
403 43150320 SENSOR ASSY, SERVICE, TG 1
404 43158193 REACTOR, CH-43-2Z-T 1
405 43160575 TERMINAL BLOCK, 2P, 20A 1
406 4316V438 P.C. BOARD ASSY, MCC-1402 1
407 43160582 TERMINAL, 4P 1
