FLY IDRO DSA

18 7193505 - IT-EN-DE-FR

3. FIRE SAFETY

When installing the product, the following safety measures must be observed:

a) In order to ensure sufcient thermal insulation, respect the minimum safety distance from objects or furnishing components ammable

and sensitive to heat (furniture, wood sheathings, fabrics. etc.) and from materials with ammable structure (see Picture 5 at page 54 -

A). All the minimum safety distances are shown on the product data plate and lower values must not be used.

b) In front of the furnace door, in the radiation area there must be no ammable or heat-sensitive objects or material at a distance of less

than 100 cm. This distance can be reduced to 40 cm where a rear-ventilated, heat-resistant protection device is installed in front of the

The Product must always operate exclusively with the ash drawer inserted. The solid combustion residues (ash) must be collected in a

sealed, re resistant container. The Product must never be on in the presence of gaseous emissions or vapours (for example glue for

linoleum, petrol etc.). Never deposit ammable materials near the Product.

During combustion, thermal energy is released which leads to considerable heating of the surfaces, doors, handles, controls, glass parts,

the ue gas pipe and possibly the front part of the appliance. Avoid contact with these elements unless using suitable protective

clothing or accessories (heat resistant gloves, control devices).

Ensure children are aware of these dangers and keep them away from the furnace when it is on.

When using the wrong fuel or one which is too damp, due to deposits present in the ue, a ue re is possible.

3.1. IN A EMERGENCY

If there is a re in the ue connection :

When the ue stops burning, have it checked by a specialist to identify any cracks or permeable points.

4. DESCRIPTION

Denition: thermo-replace according to EN 13240.

The appliance is composed of painted and galvanised sheet steel and cast iron.

The replace is found inside the boiler, is built in 4 mm thick steel and is reinforced using welded nails. The water in the heating system

circulates in the boiler, which absorbs the heat produced in the replace.

The ceramic glass window (resistant up to 700°C) of the door provides a lovely view of the burning ames and prevents sparks and smoke

from getting out.

Room heating takes place:

a) by radiation: the heat is radiated into the environment through the panoramic window and the hot external surfaces of the thermo-

With this air register, it is adjusted the passage of primary air into the low part of the stove and through particular channels ows in the

fuel direction. The primary air is necessary for the combustion process during lighting. The ash drawer must be regularly emptied, so

During this phase, open all the bleed valves of the radiators to prevent the formation of air sacks, checking the outlet of water to avoid

unpleasant oodings.

The watertight test of the installation is performed with the pressure of expansion tank open.

The installation must always be full of water even when the thermo-product is not used. During winter season the non use has

to be faced by adding antifreeze substances.
