“heaterSteam” +0300075EN - rel. 1.2 - 29.09.2015
8. CONFIGURATION PARAMETERS
8.1 Parameter access and setting
See chapter 6 “Start and user interface”
Note: variable type: A = analog I=full, D = digital.
8.2 Basic operation parameters
Par. Description UM range def
Variable
type
CAREL
protocol
notes
A0 Operating mode 0,…,3 2 l 9
0= ON/OFF command
1= external proportional signal
2= autonomous adjusting with room probe
3= autonomous adjusting with room probe and limit probe
A1 Unit of measurement: 0,1 0 l 10 0=°C, kg/h – 1 = °F, Ib/h
A2
signal applied to room probe input
autonomous control (A0=1, 2 or 3)
0,…, 4 0 I 11
0= 0…1 V
1= 0…10 V
2= 2…10 V
3= 0…20 mA
4= 4…20 mA
A3 room probe minimum %rH 0, .., (A4) 0 I 12 can only be accessed in autonomous control (A0=2 or 3)
A4 room probe maximum %rH (A3), .., 255 * 100 I 13
A5 room probe calibration %rH -10.0,…,10.0 0 A 4
A6
signal applied to the outlet probe
input can only be accessed in
autonomous control with outlet
probe (A0=3)
0,…,4 0 I 14
0= 0…1 V
1= 0…10 V
2= 2…10 V
3= 0…20 mA
4=4…20 mA
A7 minimum limit probe %rH 0,…,(A8) 0 I 15 can only be accessed in autonomous control with outlet probe (A0=3)
A8 maximum limit probe %rH (A7), .., 100 100 I 16
A9 limit probe calibration %rH -10…10 0 A 5
Tab. 8.a
8.3 Auxiliary function parameters
Par. Description UM range def
Variable
type
CAREL
protocol
notes
b0 period of modulation (if set to 0 modulation is disabled) s 0,…,199 ** I 17
b1 Check the functions assigned to parameter b1 in the table given in chapter 12. 0…63 0 I 18
b2 start pre-heating off set (referred to set point) %% r.H. 2,…,19.9 3.0 A 6
They can only
be accessed
with pre-heating
function enabled
(b1=1 or 3)
b3 pre-heating temperature °C 70,…,90 80 I 19
b5 conductivity pre-alarm threshold (displayed as 1•2) μS/cm 0,…,2000 1250 I 21
b6 conductivity alarm threshold (displayed as 1•5) μS/cm 0,…,2000 1500 I 22
b7 control of the foam detection threshold (if set to 0 foam detection is disabled) % 0,…,100 50 I 23
b8
setting the maximum number of evaporation cycles between two drain cycles for
dilution step:1
The actual value used is internally calculated based on the value read for the conduc-
tivity of the water supply (the higher the conductivity, the lower the calculated value),
however if the calculated value is greater than b8, b8 will be used. If b8=0, it shall
be automatically set to 2 at fi rst heaters start-up and if conductivity measured in the
supply water is <= 100 μS/cm, or at 5.
- 0…50 0 I 33
b9 minimum time for passing from 0 to 100% of steam production min 0,…,100 0 I 24
bA percentage reduction in the duration of the water fi ll time % 20…100 100 I 34
bb
steam production value (step 0.1%)
it allows the user to “adjust” the value displayed by parameter d3, if there is a system
available for measuring the diff erence between the value displayed d3 and the actual
steam production.
Example of use:
d3= 10 kg/h and bb= +10% changes d3 to 11 kg/h (= 10 kg/h + 10%)
% -19.9…19.9 0 A 7
bC automatic total drain for inactivity (see par. 12) days 1…199 3 I 35
bd user-adjustable duration of dilution drain (see par. 12) % 0…190 100 I 36
bE fi ll-up cycle duration, after dilution drain, in pwn mode s 1…199 5 I 37
Tab. 8.b
