![Carel UR053HL102 [3/72] Attention](/views2/1339072/page3/bg3.png)
3
ENG
“heaterSteam” +0300075EN - rel. 1.2 - 29.09.2015
WARNINGS
The humidifi ers manufactured by CAREL Industries are advanced products,
whose operation is specifi ed in the technical documentation supplied with
the product that can be downloaded, even prior to purchase, from the
website www.carel.com. Every product made by CAREL Industried, in relation
to its advanced level of technology, requires a qualifi cation/ confi guration /
setup phse in order to best fulfi l your specifi c application. The lack of such
phase of study, as indicated in the manual, can cause the fi nal product to
malfunction, of which CAREL Industries cannot be held responsible. The
client (builder, developer or installer of the fi nal equipment) assumes all
responsibility and risk relating to the confi guration of the product in order to
achieve the expected results in relation to the specifi c fi nal installation and/
or equipping. In this case, subject to specifi c agreements, CAREL Industries
acts as a consultant for the success of the installation / start-up / use of the
machine, but in no case does it accept liability for proper operation of the
humidifi er and of the fi nal plant, should the warnings and recommendations
in this manual or in any other technical documentation of the product not
be followed. In particular, in addition to the obligation to observe the above
mentioned warnings and recommendations for proper use of the product, we
recommend paying attention to the following warnings:
DANGER ELECTRIC SHOCK: The humidifi er includes live electrical parts.
Disconnect the power supply before accessing internal parts, in case of
maintenance and during installation.
DANGER WATER LEAKS: The humidifi er automatically and constantly fi lls/
drains quantities of water. Malfunctions in the connections or humidifi er may
cause leaks.
DANGER OF BURNS: The humidifi er contains hot parts and delivers steam
at 100 °C / 212 °F.
• The product is designed exclusively to humidify rooms either directly or
through distribution systems (ducts).
• Installation, operation and maintenance must be performed by qualifi ed
personnel, aware of the necessary precautions and able to perform the
required operations correctly.
• All operations on the product must be carried out according to the
instructions given in this manual and on the labels applied to the
product. Any uses or modifi cations unauthorized by the manufacturer are
considered improper. CAREL Industries denies all responsibility for such
unauthorized uses.
• Do not attempt to open the humidifi er in any way other than the ones
described in the manual.
• Follow all local regulations while installing the humidifi er.
• Keep the humidifi er out of the reach of children and pets.
• Do not install and use the product near objects that can be damaged
by contact with water (or condensate). CAREL Industries denies all
responsibility for direct or indirect damage as a result of loss of water from
the humidifi er.
• Do not use corrosive chemicals, aggressive solvents or detergents to clean
the internal or external parts of the humidifi er, unless specifi cally indicated
in the user’s manual.
CAREL Industries adopts a continuous development policy. Therefore, CAREL
reserves the right to carry out modifi cations and improvements to any
product described in this document without prior notice. The technical data
in the manual can undergo modifi cations without forewarning. The liability
of CAREL Industries in relation to its own product is governed by CAREL
Industries general contract conditions published on the website www.carel.
com and/or by specifi c agreements with clients; in particular, within the limits
set by the applicable law, in no way will CAREL Industries, its employees or
its branch offi ces/affi liates be responsible for any lack of earnings or sales,
loss of data and information, cost of replacement goods or services, damage
to objects or persons, work interruptions, or any direct, indirect, accidental,
patrimonial, coverage, punitive, special or consequential damage in any way
caused, be they contractual, out-of-contract, or due to negligence or other
responsibility originating from the installation, use or inability of use of the
product, even if CAREL Industries or its branch offi ces/affi liates have been
warned of the possible damage.
ATTENTION
NO POWER
& SIGNAL
CABLES
TOGETHER
READ CAREFULLY IN THE TEXT!
Separate the probe cables and the digital input cables as much as possible
from the inductive load and power cables to prevent possible electro-
magnetic interference.
Never introduce power cables and signal cables (including those of electric
control board) into the same cable troughs.
The installation of the product must absolutely include the grounding
connection, using the special yellow-green terminal on the terminal block.
Do not use the neutral as grounding connection.
DISPOSAL
The humidifi er consists of metal parts and plastic parts. With reference to the
European Parliament and Council Directive 2002/96/EC issued on 27 January
2003 and the related national implementation legislation, please note that:
1. WEEE cannot be disposed of as municipal waste, said waste must be
collected separately;
2. the public or private waste collection systems defi ned by local legislation
must be used.
3. the equipment may contain hazardous substances: the improper use or
incorrect disposal of such may have negative eff ects on human health
and on the environment;
4. the symbol (crossed-out wheeley bin) shown on the product or on the
packaging and on the instruction sheet indicates that the equipment has
been introduced onto the market after 13 August 2005 and that it must
be disposed of separately;
5. in the event of illegal disposal of electrical and electronic waste, the
penalties are specifi ed by local waste disposal legislation.
Warranty for materials: 2 years (from the manufacture date, excluding
consumables).
Certifi cation: the quality and safety of CAREL products are guaranteed by
CAREL’s ISO 9001 certifi ed design and production system, as well as
marking.
