2.7 Smart Switches

e motherboard has four smart switches: Power Switch, Reset Switch, Clear CMOS

Switch and XMP Switch.

Power Switch

(PWRBTN1)

(see p.1, No. 17)

Power Switch allows users

to quickly turn on/o the

system.

Reset Switch

(RSTBTN1)

(see p.1, No. 15)

Reset Switch allows

users to quickly reset the

system.

Clear CMOS Switch

(CLRBTN1)

(see p.3, No. 19)

Clear CMOS Switch

allows users to quickly

clear the CMOS values.

XMP Switch

(XMP_ON1)

(see p.1, No. 6)

e XMP switch allows

users to easily load XMP

proles to automatically

congure the overclocked

DRAM voltages for stable

operation.

is function is workable only when you power o your computer and unplug the

power supply.
