Robert Bosch Hausgeräte GmbH 15
Fruit press attachment
(some models)
Puréeing soft fruit, tomatoes, apples, pears or
rosehips. The selection of the filter insert
determines the content of fruit pulp in the juice.
Do not use for puréeing fruit that contains pips
the same size as the holes in the filter insert of
the purée attachment (e.g. raspberries).
Warning!
Do not process frozen fruit or vegetables.
Remove stones (cherries, plums, apricots,
etc.).
Fig.
Insert worm gear into the housing.
Insert filter insert into the filter holder.
Press in filter insert all the way.
Insert filter holder into threaded ring.
Screw on threaded ring with filter holder
clockwise. Lug on the filter holder must be
situated in the recess in the housing.
Do not tighten the threaded ring too tight.
Screw pulp nozzle into the filter holder.
Attach outlet funnel to the filter holder and
engage.
Put the completely assembled fruit press
attachment, inclined slightly to the right,
on the drive.
Turn fruit press attachment upwards until
it engages.
Tighten threaded ring on the fruit press
attachment.
Attach filling tray.
Place suitable container under the juice
outlet opening.
Place bowl or plate under the opening
of the pulp nozzle.
Insert the mains plug.
Place the food to be processed in the
filling tray.
Switch appliance on with the On/Off
button.
Press food down using the pusher.
Do not exert too much pressure!
Filter insert may be damaged.
Application instructions:
– First loosen the pulp nozzle until the pulp
(solid constituents) is still moist when
it flows out.
– Then slowly close the pulp nozzle until
juice and pulp come out in the required
form.
After using the appliance:
Switch appliance off with the On/Off
button.
Remove mains plug.
Pull out the pusher.
Remove filling tray.
Remove the fruit press attachment.
Holding down the release button, turn the
attachment to the right and remove.
Disassemble fruit press attachment.
Disassembly is in reverse order.
Clean all parts, see “Cleaning and
servicing”.
Shredding attachment
(some models)
For shredding and slicing cheese, fruit, vege-
tables, nuts, almonds, dried bread rolls and
pieces of bread, chocolate and other hard
foods.
Fig.
Place required insert in the housing
of the shredding attachment.
The insert is automatically locked when
the appliance is switched on.
Put the shredding attachment, inclined
slightly to the right, on the drive.
Turn shredding attachment upwards until
it engages.
en
Risk of injury
Before fitting/removing attachment, wait
until the drive has come to a standstill and
pull out the mains plug.
Do not reach into the feed tube. Always
use the stuffer to push food down the hole.
Risk of injury
Before fitting/removing attachment, wait
until the drive has come to a standstill and
pull out the mains plug.
Do not grip the sharp blades and edges
of the shredding and slicing inserts.
Do not reach into the feed tube. Always
use the stuffer to push food down the hole.
