ENGLISH
ENGLISH
31
Insert the motor housing (3) with the mixing rod (4) into the
holding device.
Remove the mixing rod
• Remove the mixing rod from the motor housing by turning it
briefl y in an anticlockwise direction.
Attaching Accessories
• If you would like to use the Multiknife or the whisking disc,
fi rst place the attachment on the shaft of the mixing rod (see
Illustration A) and then push it into the position shown in
Illustration B. If necessary, hold the shaft at the open end of
the mixing rod tightly.
NOTE:
• Make sure that the pin located on the shaft fi ts into
the slot of the attachment. Only in this case can the
attachment be inserted completely onto the shaft!
• Use the lifter (15) as a tool in order to release the
components again (see Illustration C).
Attaching the Mixing Rod
• Lock the mixing rod into place by turning once. The marker
dots (3a) are now positioned one above the other.
Whisk
• If you would like to use the whisk (9), replace the mixing rod
by the adapter (10). Lock the whisk into place by applying
moderate pressure to the driveshaft of the adapter.
Function and Accessories
Two-level control switch (2):
Level •: At this level it is possible to use the speed
control to regulate the number of revolutions per
minute.
Level ••: This provides the maximum speed and cannot
be regulated.
Table of Functions and Accessories (see below)
Using the Mixing Rod and Whisk
WARNING: Make sure that the plug is not inserted!
1. Select an accessory. Please note the section „Bevore Use“.
2. Fill the food to be mixed into the mixing bowl ((5) max. 0.6
litres). The mixing rod or whisk should be fully immersed.
3. Use the regulator (1) to set the corresponding speed. Please
refer to the table.
4. Hold the device in such a way that you are able to operate
the two-level control switch (2) with your fi ngers.
5. Only connect the machine to a properly installed safety
socket, 230 V/50 Hz.
6. Press one of the buttons of the two-level control switch.
7. You can achieve pulse operation by pressing the button at
intervals and then releasing it.
8. The device switches itself off when the button is released.
9. Pull out the plug from the socket after use. Clean and put
the device away as described in „Cleaning and Mainte-
nance“.
Changing of the metal attachments
• Remove the attachment already inserted on the shaft of the
mixing rod (4) with the release button (15).
• The side with the slot is used to remove the attachments.
Using the Multi-chopper
WARNING: Make sure that the plug is not inserted!
1. Release the mixing rod (4) by turning it and pulling it out of
the motor housing (3).
2. Place the multiple chopping machine on a fl at, level surface
and then remove the lid (12).
3. Fill the transparent beaker (13). Do not fi ll the beaker to the
rim, but only ¾ of the beaker capacity.
4. Seal the bowl again with the lid; the recesses on the lower
edge of the lid and on the upper edge of the bowl must
interlock.
5. Place the motor casing on the upper opening of the lid and
fasten the multi-chopper by turning it to the right.
Table of Functions and Accessories
Attachment Function Speed Operating Time
Beater disk (6)
For mixing and stirring milk shakes, drinks, omelette batter,
sauces and cosmetic emulsions
Level •,
set speed control to 1–2.
max. 3 min.
Whisk (9)
For beating cream, egg white (max. 4 egg whites) and
blancmange and whipping up sauces, sponge cake mixture
and other airy and foamy foods
Level •,
set speed control to 2–4.
max. 4 min.
Multiple blade
(7)
With the addition of liquid can be used for chopping,
mincing and pureeing boiled vegetables, soft fruit and baby
food and for the straining of soups and sauces
Level •,
set speed control to 1–5 or
level ••
max. 3 min.
Chopping
blade (14)
For cutting, chopping or mincing raw or cooked meat and
hard-fi bred vegetables
Level •,
set speed control to 1–5 or
level ••
max. 3 min.
05-SMS 2759 neu.indd 3105-SMS 2759 neu.indd 31 02.05.2008 10:51:58 Uhr02.05.2008 10:51:58 Uhr
