GRAPHITE 59G806 [21/224] Operation adjustments

When xing the mitre saw to a workbench ensure that:

Ɣ The workbench top surface is at and clean.

Ɣ Screws and bolts are tightened equally and moderately (mounting bolts must be tightened so the base is not

stressed or deformed). In case of over-stress there is danger of breaking the base.

DUST EXTRACTION

To prevent dust accumulation and provide maximum eciency, you can connect the mitre saw to an industrial

vacuum cleaner using the dust extraction connector (28) Alternatively, you can collect the dust in the dust-bag

(included) after installing it onto the dust extraction connector. To install, put the dust bag (29) onto the dust

extraction connector (28) (g. A). To empty the dust bag, remove it from the dust extraction outlet and open the

zip-fastener that allows to access inside the bag.

To achieve optimal dust extraction empty the bag when it is 2/3 full.

USING THE EXTENSION ARM (HEAD)

There are two positions of the extension arm – upper and lower. To release the extension arm from locked lower

position, do as follows:

Ɣ Press and hold down the extension arm.

Ɣ Pull the head locking pin (9).

Ɣ Hold the extension arm as it raises to its upper position.

To lock the extension arm in the lower position, do as follows:

Ɣ Press and hold the disc guard lever (5).

Ɣ Release the pressure downwards onto the extension arm until it is located in its lower position.

Ɣ Lock the extension arm in this position, sliding the head locking pin in (9).

VERTICAL CLAMP

The vertical clamp (g. B) can be installed in the saw base at either side of the work table and is fully

adjustable to size of the workpiece to be cut. Do not use the saw without using the vertical clamp.

Ɣ Loosen the vertical clamp mounting knob (30) to the base on the side, which the vertical clamp will be installed.

Ɣ Install the vertical clamp by sliding it into the hole in the mitre saw base and tighten the vertical clamp

mounting knob (30) to the mitre saw base.

Ɣ Once the vertical clamp arm position is adjusted (31) to the workpiece, tighten the vertical clamp arm

locking knob (32) and workpiece mounting knob (33).

Ɣ Make sure the workpiece is secured.

OPERATION / ADJUSTMENTS

Make sure the mitre saw is disconnected from power supply, before any adjusting or mounting works are

commenced. To ensure safe, precise and ecient operation of the mitre saw, proceed with all adjustment

procedures as a whole.

After nishing all the setting and adjustment procedures, ensure that all spanners are collected. Check

that all threaded connections are properly tightened.

When making adjustments, ensure that all external parts work properly and are in good condition. Any

worn or damaged part must be replaced by qualied personnel before starting to use the mitre saw.

SWITCHING ON /SWITCHING OFF

The mains voltage must correspond to the value specied on the mitre saw nameplate.

Switch on the mitre saw only when the cutting disc is away from the workpiece to be cut.

The mitre saw features the switch lock button (3) that protects against accidental starting.

Switching ON

Ɣ Press the switch lock button (3).

Ɣ Press and hold the switch button (4).

Switching OFF

Ɣ Release pressure on the switch button (4).
