Whenever the projected light beam is not parallel to the previously made cut, proceed as follows:

Ɣ Slightly rotate the laser to the left or right (38) (g. G) in the laser unit housing (26), until the laser beam

is position in parallel. Do not rotate the laser unit using force and by more than a few degrees.

Ɣ When any lateral adjustment is necessary, loosen the laser unit mounting bolts (39) and move the laser

unit to the left or right, until the red line is parallel to the cut

Dust arising from cutting may suppress laser light, therefore it is necessary to clean the laser lens

occasionally.

STARTING THE SAW

Before the switch button is pressed, ensure that the mitre saw is assembled and adjusted properly and

accordingly to instructions in this manual.

The described mitre saw is designed for the right-handed.

Ɣ Press the switch lock button (3).

Ɣ Press the switch button (4).

Ɣ Allow the saw motor to reach its full rotational speed.

Ɣ Press the cutting disc guard lever (5).

Ɣ Lower the extension arm towards a workpiece.

Ɣ Release pressure on the cutting disc guard lever (5).

Ɣ Make a cut.

STOPPING THE SAW

Ɣ Release pressure on the switch button (4) and wait until the cutting disc comes to full stop.

Ɣ Raise the extension arm of the saw by putting it aside from the workpiece.

Temporary sparking of brushes inside the electric motor is normal when the mitre saw stops. Do not

stop the cutting disc by applying lateral pressure.

CUTTING WITH THE SAW

The workpiece should be fastened so it does not impede using the mitre saw. Before switching the

saw on, move its head to the lower position to ensure that the saw head and cutting disc guard are

free to move. Make sure the cutting disc guard can reach its extreme position.

Before the cut is commenced, make sure the working table locking knob (23) and the head locking lever (14) of the

mitre saw are tightened and secured.

Ɣ Connect the mitre saw to the power mains.

Ɣ Make sure the power cord is away from the cutting disc and base of the device.

Ɣ Place the workpiece onto the working table and make sure it is secured so as it cannot move during the cut.

Ɣ Move the mitre saw heat to the extreme rear position and lock the guide (13) using the guide locking

knob (12).

Ɣ Unlock the head and cutting disc guard.

Ɣ Press the switch lock button and start the saw with the switch (wait until the cutting disc reaches its

maximum rotational speed).

Ɣ Slowly lower the saw head.

Ɣ Start cutting by moderately pressing the head down.

Insucient tightening of the locking knobs may cause unexpected movement of the cutting disc

to the upper surface of the workpiece. It puts an operator to danger of being hit with a piece of

material.

CUTTING WITH THE MOVEMENT OF THE SAW EXTENSION ARM (HEAD) OF THE MITRE SAW

The feeding of the saw extension arm allows forward and backward movement of the cutting disc to cut wider

workpieces.

Ɣ Set the extension arm in the upper position.

Ɣ Loosen the guide locking knob (12).

Ɣ Before switching on the saw, pull the extension arm to yourself while holding it in the upper position.

Ɣ Press the switch lock button (3) and start the saw.
