23
If the measured angle is not 90º, then the following adjustment is necessary:
Ɣ Loosen the retaining nut and rotate the 0º (42) angle adjusting bolt (g. E) to the right or left in order to
increase or decrease the cutting disc tilt angle.
Ɣ Once the perpendicular position of the cutting disc and working table is set, allow the head to return to its
upper position.
Ɣ Holding the 0º (42) angle adjusting bolt, tighten the retaining nut.
Ɣ Lower the head and make sure that the set angle corresponds to indications on the head tilt angle scale
(34), if necessary, adjust the head tilt angle indication (35) (g. E).
Similar adjustment should be made for the angle of 45º of the head for mitre sawing by means of the 45º
(43) (g. E) angle adjusting bolt.
CHECKING AND ADJUSTING THE PERPENDICULAR POSITION OF THE CUTTING DISC IN RELATION
TO THE FENCE
Perform this procedure each time the fence is removed or replaced. Proceed with the adjustment
only after the perpendicularity of the cutting disc in relation to the working table is set. The fence is
used as a stop for workpiece.
Ɣ Loosen the working table locking knob (23), and press and hold the automatic setting lever (22) and set
the working table to the position of 0º.
Ɣ Lower the saw head to the extreme lower position.
Ɣ Put a protractor or any other angle measurement tool to the cutting disc.
Ɣ Move the angle measurement tool to the fence (15).
Ɣ The measurement should indicate 90º.
If it is necessary to adjust the angle, proceed as follows:
Ɣ Loosen the fence mounting bolts (15) to the base.
Ɣ Adjust the position of the fence (15) so that it is perpendicular to the cutting disc.
Ɣ Tighten the fence mounting bolts.
SETTING THE EXTENSION ARM HEAD FOR MITRE CUTTING
The extension arm can be tilted at any angle ranging from 0º to 45º – for mitre sawing (g. E).
Ɣ Pull the head locking pin (9) and release and allow the extension arm to rise slowly to the upper position.
Ɣ Loosen the head locking lever (14).
Ɣ Tilt the extension arm to the left at the required angle, which you can read on the head tilt angle scale
(34) using the head tilt angle indicator (35) (g. E).
Ɣ Tighten the head locking lever (
14).
If it is necessary to adjust both angles (in both planes, horizontal and vertical) for combination
sawing, always set the mitre sawing angle rst.
CHECKING OPERATION OF THE LASER
The laser unit emits a laser beam that projects the line on a workpiece that indicates how the workpiece will
be cut. The proper adjustment of the laser line projection has been adjusted during the production process.
Nevertheless, for precision works, check this adjustment before starting to saw.
Ɣ Place batteries in the battery compartment (36) (g. F) paying attention to polarity.
Ɣ Set the working table in the position, where the working table angle indicator (21) is aligned with the
point of 0º on the angle scale of the working table (20), while the head tilt angle indicator (35) (g. E) is
aligned with the point of 0º on the head tilt angle scale (34) (g. E).
Ɣ Fasten a piece of waste material to the working table (25) and make a cut.
Ɣ Release the extension arm and leave waste material xed to the working table of the saw.
Ɣ Set the laser switch button (37) to the ON position „I” (marked).
Ɣ The projected light beam should be parallel to the previously made cut.
LASER ADJUSTMENT
When the laser guiding beam is adjusted, do not look at the source of the laser beam or its reection on a
reective surface. Always switch o the laser unit, when the laser is not used.
