are flashing in different configurations, see description below.
• All diodes are flashing - battery is empty and requires
charging.
• 2 diodes are flashing - the battery is partially discharged.
• 1 diode is flashing - the battery level is high.
Once the battery is charged, the diode (11) on the charger lights
green, and all battery level diodes (14) light continuously. After
some time (approx. 15 s) battery level indication diodes (14) turn
off.
Do not charge the battery for more than 8 hours. Exceeding
this time limit may cause damage to battery cells. The charger
will not turn off automatically when the battery is full. Green
diode on the charger will remain on. Battery level indication
diodes turn off after some time. Disconnect power supply
before removing the battery from the charger socket. Avoid
consecutive short chargings. Do not charge the battery after
short use of the tool. Significant decrease of the period
between chargings indicates the battery is worn out up and
should be replaced.
Batteries heat up when charging. Do not operate just
after charging – wait for the battery to cool down to room
temperature. It will prevent battery damage.
BATTERY LEVEL INDICATION
The battery is equipped with signalisation of the battery level (3
LED diodes) (14). To check battery level status, press the button
for battery level indication (13) (fig. C). When all diodes are lit,
the battery level is high. When 2 diodes are on, the battery is
partially discharged. When only one diode is lit, the battery is
discharged and must be recharged.
INSTALLATION AND ADJUSTMENT OF THE WHEEL GUARD
Wheel guard protects the operator from splinters, accidental
contact with the working tool or sparks. It should be installed at
all times. Make sure that protective section faces the operator.
The wheel guard design allows for setting the guard tool free in an
optimal position.
• Loosen and pull away the lever (8) on the wheel guard (5).
• Turn the wheel guard (5) to desired position.
• Lower the lever (8) to lock.
Deinstallation and setting of the wheel cover are similar to
installation, only the sequence of actions is reversed.
REPLACEMENT OF WORKING TOOLS
Wear work gloves during working tool replacement.
Spindle lock button (1) is used only to lock the grinder spindle
for installation or removal of working tool. It cannot be used as
a brake button when the wheel is rotating. Otherwise the grinder
may be damaged or the user may be injured.
WHEEL INSTALLATION
For grinding and cutting wheels below 3 mm thickness, screw the
outer ange (6) nut onto the at surface on the wheel side (g. D).
• Press the spindle lock button (1).
• Insert the special key (included) into holes of the outer flange (6)
(g. E).
• Turn the key to loosen and remove the outer flange (6).
• Install wheel, make sure it is pressed against the inner flange
surface (7
).
• Screw the outer flange (6) on, slightly tighten with the special key.
You can remove the wheel by following the installation procedure in
reverse sequence. During installation, the wheel should be pressed
against surface of the inner flange (7) and centred when seated on
its neck.
INSTALLATION OF WORKING TOOLS WITH THREADED HOLE
• Press the spindle lock button (1).
• Do not grind with wheels designed for cutting. Cutting wheels
work with front edge surface and grinding with side surface of the
wheel can cause damage, and in consequence personal injuries of
the operator.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on
the drawing pages of this manual.
1. Spindle lock button
2. Switch lock button
3. Switch
4. Additional handle
5. Wheel guard
6. Outer flange
7. Inner flange
8. Lever (wheel guard)
9. Battery
10. Battery lock button
11. LED diodes
12. Charger
13. Button for battery level indication
14. Battery level indicator (LED)
* Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Wheel guard - 1 pce
2. Special key - 1 pce
3. Additional handle - 1 pce
PREPARATION FOR OPERATION
REMOVING AND INSERTING THE BATTERY
• Push the battery lock button (10) and slide out the battery (9)
(fig. A).
• Insert charged battery (9) into the handle holder, you should
hear when the battery lock button (10) snaps.
BATTERY CHARGING
The device is supplied with partially charged battery. The battery
should be charged in ambient temperature between 4°C and
40°C. New battery, or one that has not been used for a long
time, will reach full efficiency after approximately 3 to 5 charge/
discharge cycles.
• Remove the battery (9) from the device (fig. A).
• Connect the charger to mains socket (230 V AC).
• Slide the battery (9) into the charger (12) (fig. B). Ensure the
battery is properly fitted (pushed to the end).
When the charger is connected to a mains socket (230 V AC), the
green diode (11) on the charger turns on to indicate connected
supply.
When the battery (9) is placed in the charger (12), the red diode
(11) on the charger turns on to indicate that the charging is in
progress.
Simultaneously, green diodes (14) of the battery level indication
