71GW13-024_v05
4. Filling the water tank
CAUTION! Pour the water into the tank (1) only when the cord is
unplugged from the socket. The valve at the bottom part of the tank
prevents the water from leakage.
● Remove the water tank (1) by pulling it upward (Fig. 1).
● Open the cover of the water tank (1) and ll it up with fresh, cool water
(Fig. 2). Do not exceed the maximum (MAX) level.
● Place the tank (1) in its place and press it.
● Close the cover of the tank (1).
● The tank may be lled without removing it from the machine, e.g. by
pouring the water out of a pitcher.
CAUTION! Do not use the espresso machine, when the tank (1) is
empty. Before brewing coffee it is vital to check whether there is
any water in the tank (1). Do not ll the tank (1) with hot water. Due
to hygienic reasons do not leave any water in the tank for longer
periods.
CAUTION! Remember to avoid low levels of water level in the tank
(1). In such a case the machine will stop working, give out a sound
signal, which will end only if the tank is lled (1), furthermore the
no-water indicator will ash on the display panel.
5. Warming up the cups
Using a cup warmed up to a certain temperature before brewing coffee
increases the taste of the coffee itself and creates a thick froth on its
surface.
The machines gives you two ways of warming up a cup. The rst one is to
warm it by means of hot water coming out of the steam/hot water nozzle
(10) acting accordingly to paragraph 14.
The second way is to place the cups before the coffee brewing process on
the cup-warming plate (2) situated at the top of the espresso machine.
CAUTION! The coffee maker was designed with a power consumption
protection device, and after one hour of standing-by (with no coffee
making or other processes active), it automatically turns itself off.
This means that it is impossible for the heating panel to heat up for
more than one hour.
6. Before rst use (rinsing the machine)
Before using the machine for the rst time or if it has not been used for
a longer period, it is necessary to rinse it.
6.1. Rinsing the machine for the espresso function
6.1.1. Unplug the machine.
6.1.2. Fill the water tank (1) according to paragraph 4.
6.1.3. Attach the empty lter handle (6) to the brew head (4), by turning it
with a rm motion to the right (Fig. 3).
6.1.4. Place a container on the drip tray grid (7), directly under the brew
head (4).
6.1.5. Plug the cord into the socket. The espresso machine will turn on,
the display panel and the power on/off button (A) will ash, and
the power on/off indicator on the display panel will be lit.
6.1.6. Push the power on/off button (A), you will hear a sound signal.
6.1.7. The indicator on the display panel will begin to whirl, signalizing
that the espresso machine is heating up.
6.1.8. When the indicator stops whirling, you will hear a sound signal
informing you that the machine is ready for use (has reached the
right temperature).
6.1.9. Choose the maximum amount of coffee (60 ml in our case) by
pressing the coffee amount select button (C). After each push
you will hear a sound signal and the display panel will show the
following numbers in turn: 30, 40, 50, 60, P1, P2, etc. Push the
button as many times as it is necessary the indicator to show 60.
6.1.10. Choose double cup of coffee pressing the single/double cup select
button (B). After each push you will hear a sound signal.
If you have chosen to select a double cup, the display panel will
indicate . In case of a single cup the display panel will
indicate .
6.1.11. Press the brew coffee button (F). You will hear a sound
signal.
6.1.12. Hot water will come out of the machine and the display panel
will indicate (after choosing a double cup) or (after
choosing a single cup).
6.1.13. Brewing will be automatically stopped after a given amount of
water. You will hear two sound signals, and the display panel will
indicate in case of choosing a double cup or in case
of a single cup.
6.1.14. Repeat step 6.1.11. three times.
6.2. Rinsing the machine for the steam mode
6.2.1. Check if there is water in the water tank (1). If there is no water, ll
the water tank (1) according to paragraph 4.
6.2.2. Press the steam button (E).You will hear a sound signal. The
display panel will lit the indicator, signalizing that the espresso
machine is now in steam mode.
6.2.3. The indicator on the display panel will begin to whirl, signalizing
that the espresso machine is heating up.
6.2.4. When the indicator stops whirling, you will hear a sound signal
informing you that the machine is ready for use (has reached the
right temperature).
6.2.5. Put a container under the steam nozzle (10) and turn the steam
control (12) to position , i.e. turn it counterclockwise, so
the sign will cover the casing of the espresso machine. Let
the machine work with the mode on for ca. 1 minute. Then turn the
steam control (12) to OFF, position, i.e. turn it clockwise, so the sign
OFF will cover the marker on the casing of the espresso machine.
Empty the container.
6.2.6. Repeat step 6.2.5. three times.
CAUTION! Push the power on/off button (A), you will hear a sound
signal. The indicator will go off on the display panel, signalizing
that the espresso machine has returned to the coffee brewing mode.
7. Adjusting water hardness
The espresso machine has been programmed with three levels of
water hardness: low (LO indicator), medium (MI indicator) and high
(HIindicator). The default level is set to MI medium. If you want to change
water hardness, press and hold the coffee amount select button (C) for
2 seconds. You will hear a sound signal and the water hardness indicator
on the display panel will start to ash. Each time you push the coffee
amount select button (C), which action is accompanied by a sound
signal water hardness level changes in the following order: medium MI
high HI low LO medium MI high HI, etc. If you choose to select
e.g. high HI level, do not push the button again. Wait 2 seconds and the
setting will be automatically saved and you will hear a sound signal.
To establish the current water hardness level, the user should to carry out
a test with a test apparatus supplied together with the espresso machine.
Put the test apparatus in the water for one second. After removing it from
the water shake the excess of water off and see the results after waiting
ca. 15 seconds. A dry test apparatus should have a green square space.
Fig. 1 Fig. 2
Fig. 3
